Cable
Class of Wire 온도
℃		 Insulation 참고 P/N LS P/N Conductot
AWG Material 구성
600V General purpose 150 XL-ETFE 82A0111-12-* LGTAD A12SB1U00-* 12 Tin-coated copper 19/35/0.080TA
600V General purpose 150 XL-ETFE 82A0111-10-* LGTAD A10SB1U00-* 10 Tin-coated copper 19/35/0.102TA
600V General purpose 150 XL-ETFE 82A0111-8-* LGTAD A08SB1U00-* 8 Tin-coated copper 19/35/0.102TA
600V General purpose 150 XL-ETFE 82A0111-6-* LGTAD A06SB1U00-* 6 Tin-coated copper 19/55/0.127TA
600V General purpose 150 XL-ETFE 82A0111-4-* LGTAD A04SB1U00-* 4 Tin-coated copper 37/45/0.127TA
600V General purpose 150 XL-ETFE 82A0111-2-* LGTAD A02SB1U00-* 2 Tin-coated copper 19/35/0.160TA
600V General purpose 150 XL-ETFE 82A0111-0-* LGTAD A0SB1U00-* 0 Tin-coated copper 19/7/20/0.160TA
600V General purpose 150 XL-ETFE 81A0111-00-* LGTAD A00SB1U00-* 2/0 Tin-coated copper 19/7/25/0.160TA
Cable
Class of Wire 온도
℃		 Insulation LS P/N Conductot
AWG Material 구성
1000V General purpose 150 XLPE LSHFMC 1X16AWG-* 16 Tin-coated copper 7/40/0.080TA
1000V General purpose 150 XLPE LSHFMC 1X14AWG-* 14 Tin-coated copper 7/60/0.080TA
1000V General purpose 150 XLPE LSHFMC 1X12AWG-* 12 Tin-coated copper 19/40/0.080TA
1000V General purpose 150 XLPE LSHFMC 1X10AWG-* 10 Tin-coated copper 19/60/0.080TA
1000V General purpose 150 XLPE LSHFMC 1X8AWG-* 8 Tin-coated copper 19/35/0.127TA
1000V General purpose 150 XLPE LSHFMC 1X6AWG-* 6 Tin-coated copper 37/29/0.127TA
1000V General purpose 150 XLPE LSHFMC 1X4AWG-* 4 Tin-coated copper 37/45/0.127TA
1000V General purpose 150 XLPE LSHFMC 1X2AWG-* 2 Tin-coated copper 37/45/0.127TA
1000V General purpose 150 XLPE LSHFMC 1X0AWG-* 0 Tin-coated copper 19/7/20/0.160TA

특징

  1. 150℃의 내열성과 탁월한 난연특성을 보유하였으며 굴곡에 우수한 세선도체 및 고유연성 절연재질을 적용하여 포설시
    유연성을 요구하는 좁은 공간 배선에 적합하도록 제작
  2. 美 국방규격 MIL-W-16878(125℃, 1000V급) 및 MIL-W-81044/9(150℃, 600V급) Wire 규격의 주요특성을 만족함
  3. ※참고 1. * 색상표시 : 0=black, 1=brown, 2=red, 3=orange, 4=yellow, 5=green, 6=blue, 7=violet, 8=gray, 9=white.
